Roller
HW-450
Operating weight: 0.3T Rated power: 6HP Exciting force: 25KN
- Operating weight: 0.3T
- Rated power: 6HP
- Exciting force: 25KN
Specifications
- Model
- HW-450
- Operating Weight (Kg)
- 200
- Exciting Force (kN)
- 25
- Amplitude (mm)
- 0.6
- Travel Speed (km/h)
- 0-4
- Climbing Ability (%)
- 30
- Vibration Frequency (Hz)
- 70
- Dimensions (mm)
- 1300*550*1650
- Steel Wheel Size (mm)
- φ430*450*1（T8)
- Engine Model
- Changchai 173F/Changfa 173F
- Engine Power (HP)
- 6
- Static Line Load (N/cm)
- 45
- Vibration Mode
- Mechanical Vibration
- Starting Mode
- Hand Pull/Electric Start
- Water Tank Capacity (L)
- None
- Hydraulic Oil Tank Capacity (L)
- 10
Walk-behind road rollers are primarily used for compacting and leveling trench foundations, roads, and sports fields, and can also be used for compacting asphalt surfaces.Product Features:1. Small operational radius, capable of working in narrow areas, suitable for trench backfilling;2. Equipped with international brand HONDA gasoline engine or well-known diesel engines, superior performance, easy to start;3. Uses international brand hydraulic drive import units, stepless speed change, forward and backward movement, hydraulic steering;4. Engine electric start, hydraulic vibration, making operation easier and more convenient;5. Installed with a luxurious seat, easy to adjust, comfortable for work;6. Uses internationally renowned NSK bearings, ensuring the machine's working performance;7. Surface plastic spraying, attractive and beautiful, rust and corrosion-resistant.Main Specifications:ModelHW-450Operating Weight (Kg)200Exciting Force (kN)25Amplitude (mm)0.6Travel Speed (km/h)0-4Climbing Ability (%)30Vibration Frequency (Hz)70Dimensions (mm)13005501650Steel Wheel Size (mm)φ4304501（T8)Engine ModelChangchai 173F/Changfa 173FEngine Power (HP)6Static Line Load (N/cm)45Vibration ModeMechanical VibrationStarting ModeHand Pull/Electric StartWater Tank Capacity (L)NoneHydraulic Oil Tank Capacity (L)10
