Bulldozer
HW17DT-GL
Power: 140KW Fuel Tank Capacity: 345L Dimensions: 5710×4230×3256mm
- Power: 140KW
- Fuel Tank Capacity: 345L
- Dimensions: 5710×4230×3256mm
Specifications
- Performance parameter
- Working weight (Without Subsoiler)
- Minimum turning radius
- 4725
- Grounding length
- 3140
- Ground pressure
- 0.025
- Engine
- Engine model
- Rated power/Rated speed
- 140/1900
- Dimensions
- Overall Dimensions
- Chassis system
- Track center distance
- Track shoe width
- 1100
- Number of track shoes (one side/piece)
- 44
- Chain track pitch
- 203
- Number of rollers(one side)
- 2
- Number of supporting wheels (one side)
- 7
- Ground clearance
- 400
- Fuel tank capacity
- Fuel tank
- Working hydraulic tank
- 75
- Dozer blade
- Shovel type
- Blade width
- 4230
- Blade height
- 960
- Lifting height
- 1140
- Cutting depth
- 485
The HW17DT-GL bulldozers have reinforced chassis, arms, and blades, which can handle the most challenging large obstacles, such as large rocks and boulders. The blade is thicker, and the arm coating is improved to enhance strength and durability. It is parricularly suitable for heavy mining applications. It is one of the best-selling products of Hengwang in Africa, where large-scale mining is prevalent.Performance parameterWorking weight (Without Subsoiler)19900kgMinimum turning radius 4725mmGrounding length 3140mmGround pressure 0.025MpaEngineEngine modelWP9HG190E474Rated power/Rated speed140/1900kw/rpmDimensionsOverall Dimensions 571042303256mmChassis systemTrack center distance 2300mmTrack shoe width 1100mmNumber of track shoes (one side/piece)44Chain track pitch203mmNumber of rollers(one side)2Number of supporting wheels (one side)7Ground clearance 400mmFuel tank capacityFuel tank345LWorking hydraulic tank75LDozer blade Shovel typeStraight Blade Blade width 4230mmBlade height960mmLifting height1140mmCutting depth485mm
