Bulldozer
HW17DH-GE
Power: 152KW Fuel Tank Capacity: 352L Dimensions:5465×3452×315mm
- Power: 152KW
- Fuel Tank Capacity: 352L
- Dimensions:5465×3452×315mm
Specifications
- Performance parameter
- Working weight (Without Subsoiler)
- Minimum turning radius
- 3745
- Grounding length
- 2675
- Ground pressure
- 0.065
- Engine
- Engine model
- Rated power/Rated speed
- 152/1800
- Dimensions
- Overall Dimensions
- Walking performance
- Forward speed
- Reverse speed
- 0-10
- Chassis system
- Track center distance
- Track shoe width
- 510
- Number of track shoes (one side/piece)
- 39
- Chain track pitch
- 203
- Number of rollers(one side)
- 2
- Number of supporting wheels (one side)
- 7
- Ground clearance
- 410
- Fuel tank capacity
- Fuel tank
- Working hydraulic tank
- 85
- Dozer blade
- Shovel type
- Blade width
- 3452/3415
- Blade height
- 1127/1200
- Lifting height
- 1010
- Cutting depth
- 520
The HW08DH-BE bulldozers have reinforced chassis, arms, and blades, which can handle the most challenging large obstacles, such as large rocks and boulders. The blade is thicker, and the arm coating is improved to enhance strength and durability. It is parricularly suitable for heavy mining applications. It is one of the best-selling products of Hengwang in Africa, where large-scale mining is prevalent.Performance parameterWorking weight (Without Subsoiler)17730kgMinimum turning radius 3745mmGrounding length 2675mmGround pressure 0.065MpaEngineEngine modelWP7Rated power/Rated speed152/1800kw/rpmDimensionsOverall Dimensions 546534523154mmWalking performanceForward speed0-10km/hReverse speed0-10km/hChassis systemTrack center distance 1880mmTrack shoe width 510mmNumber of track shoes (one side/piece)39Chain track pitch203mmNumber of rollers(one side)2Number of supporting wheels (one side)7Ground clearance 410mmFuel tank capacityFuel tank352LWorking hydraulic tank85LDozer blade Shovel typeStraight Blade /Semi-U Shape BladeBlade width 3452/3415mmBlade height1127/1200mmLifting height1010mmCutting depth520mm
