Perforadora de testigos para exploración
HW-YDX-600XL
Depth:200-600-650m Total Weight:4.5/5.5T Rated Power:92KW
- Depth:200-600-650m
- Total Weight:4.5/5.5T
- Rated Power:92KW
Especificaciones
- Model
- HW-YDX-600XL Rubber Track
- Caliber
- HTW-NTW-BTW
- Depth
- 200-600-650M
- Cooling Method
- Air Cooling + Water Cooling
- Engine
- Yuchai Turbocharged
- Rated Speed
- 2400RPM
- Rated Power
- 92KW
- Maximum Torque
- 450-1000N.M
- Maximum Speed
- 1300RPM
- Feeding Stroke
- 1900MM
- Drilling Angle
- 45-90°
- Lifting Force
- 16T
- Feeding Force
- 8T
- Walking Speed
- 3.5KM/H
- Single Machine Climbing Angle
- 45°
- Transport Dimensions
- 4000*2000*1800MM
- Total Weight
- 4.5/5.5T
Key Specifications:ModelHW-YDX-600XL Rubber TrackCaliberHTW-NTW-BTWDepth200-600-650MCooling MethodAir Cooling + Water CoolingEngineYuchai TurbochargedRated Speed2400RPMRated Power92KWMaximum Torque450-1000N.MMaximum Speed1300RPMFeeding Stroke1900MMDrilling Angle45-90°Lifting Force16TFeeding Force8TWalking Speed3.5KM/HSingle Machine Climbing Angle45°Transport Dimensions400020001800MMTotal Weight4.5/5.5T
